Salvagnini S4 punching machine

Show in original language

This Salvagnini S4 punching machine was made in 1997 in Italy. The machine can work with max. dimensions of the sheets can be stored at 3048 x 1524 mm, and a min. dimensions of the sheets can be stored at 1000 x 1000 mm.

Overview

brand: Salvagnini
year: 1997
MODEL: S4
application type: Punching
Location: Finland
machine type: Punch-Laser Combination
availability: Sold

Technical Information - Salvagnini S4

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Dimensions of sheet: 3048 x 1524 mm
- - Min. Dimensions of sheet: 1000 x 1000 mm
- - Max. Thickness: 4 mm
- - Min. Thickness: 0. 5 mm
- - Max. Height of the packs of sheets in each level: 125 mm
- - Max. Weight of the sheets in each level: 3000 kg
- - Max. Weight of a single sheet: 140 kg
- - Max. Height of store: 4600 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
