Index - G200DE-TUR-IND-2002-00004

Additional equipment

• - Bar feeder is not included in the scope of delivery
• - The scope of delivery includes the machine tool together with chip conveyor, high-pressure coolant system, filter system (fleece) and parts conveyor.
• - The mounted tool holders remain in place

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - Axis x/z working stroke 120 / 400 mm; working stroke 105 / 400 mm
  • - Cabinet mass 440 kg
  • - Spindle head admission ad 140 mm, id 85 mm
  • - Material passage max. Mm 60; front bearing diameter 100 mm; adjustable three-phase drive
  • - Hollow shaft motor: torque nm 95/140
  • - Main spindle alignment and switching device d42/d60/d65, graduation 2. 5 degrees via indexing disc
  • - Hollow clamping cylinder d60/20 for collet and clamping on the main spindle, hydraulically operated, including end of clamping stroke monitoring
  • - Tensile- compressive force ( 57 cm2 ) max 45 kn
  • - 1-clamping-pressure device for clamping cylind- on the main spindle, adjustment range 10 to 80 bar, set to the adjusted to the maximum permissible clamping operating force of the clamping medium or pressure tube
  • - Counter spindle d60; spindle head admission ad 140 mm, id 85 mm
• Qualitative Machine Benefits:
  • - Counter spindle working stroke 445 mm; rapid traverse speed 22. 5 m/min
  • - Slide driven in z-direction via ac motor and ball screw d=32 mm, axis drive secured by overload clutch secured.
  • - In working position the slide is by the ac motor against the stop
  • - Measuring system in z-axis glass scale
  • - Power at the counter spindle: power at 100/40 % ed 13/22 kw; torque 61/105 nm
  • - Cross slide 1 - x/z, with internal coolant supply and shut-off valve
  • - Shut-off valve, revolving via ac motor, ball screws d = 32 mm,
  • - Axis drives secured by overload overload clutches, weight compensation in x-axis
  • - Measuring system x-axis glass scale z-axis rod encoder
  • - Turret head with 14 stations on cross- slide 1; tool mounting holes for cylinder shank din 69880 - 25x48 mm, positioned by face gear, hydraulically locked

Payment Terms

• Payment in advance

• Asset Financing
