Trumpf TruLaser 1030 Laser Cutting Machine

Show in original language

This Trumpf TruLaser 1030 Laser Cutting Machine from 2012 has a production record of only 19770 working hours and is operated through a B&R Automation PC620 with Ethernet interface Control unit. In the past, this equipment has handled mostly mild steel of up to 5 mm and stainless steel of up to 3 mm of thickness, and was utilized for Job Shop tasks. This compact model is ideal for its efficiency with minimal C02 Gas consumption and low power consumption. On top, the TruLaser 1030 offers a highly competitive price in the market of Laser Cutters. As additional equipment, a UPS and a Compressor + Dryer are included.

Overview

brand: TRUMPF
year: 2012
MODEL: TruLaser 1030
production hours: 19770
application type: Cutting
Location: India
machine type: CO2 Laser Cutting Machine
availability: Sold

Technical Information - TRUMPF TruLaser 1030

General Data

Measurements width: 2800 mm
Measurements depth: 7800 mm
Measurements height: 2900 mm
Machine weight: 8900 kg

Control Unit

Model: PC620
Interface: Ethernet

Main drive

Laserpower: 2.5 kW
Laser type: Coax
Laser brand: Trumpf

Movement

X-AXIS Movement: 3000 mm
Y-AXIS Movement: 1500 mm

Max Material thickness

Steel: 15 mm
Stainless steel: 8 mm
Aluminum: 5 mm

Machine specific data

Number of cutting heads: 2
Size of cutting head 1: 7.5"
Size of cutting head 2: 10"
Laser turbine details: Turbine with magnetic Bearing
TASC Version: 4

Media

Main electronic connection: 400 V
Power consumption: 65 kVA
Air pressure: 10 bar
Internal cooling: Yes

Additional equipment

- UPS
- Compressor
- Dryer

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
