TRAUB TNC 42 Lathe

Show in original language

This TRAUB TNC 42 Lathe from 2004 was manufactured in Germany and has a working record of 41067 production hours. Equipped with a TRAUB System TX 8H, this efficient machine stands out for its 2 spindles working up to 5600 rpm. Tool holders, hydraulic clamps and a high pressure pump are some of the several additional tools included with the machine.

Overview

brand: TRAUB
year: 2004
MODEL: TNC 42
production hours: 41067
application type: Turning
Location: Italy
machine type: Horizontal Turning Machine
availability: Sold
control unit brand: TRAUB

Technical Information - TRAUB TNC 42

General Data

Measurements width: 4250 mm
Measurements depth: 2800 mm
Measurements height: 1917 mm
Machine weight: 4800 kg

Control Unit

Model: System TX 8H
Brand: TRAUB

Main drive

Number of spindles: 2
Spindle speed range: 5600 1/min

Movement

X-AXIS Movement: 140 mm
Y-AXIS Movement: ±35 mm
Z-AXIS Movement: 450 mm

Workpiece

Workpiece drm: 192 mm
Workpiece x: 140 mm
Workpiece y: 450 mm

Turret

Number of turrets: 2

Media

Main electronic connection: 400 V / 50 Hz
Power consumption: 18.5 kWA
Chip conveyor: Yes
Internal cooling: Yes

Additional equipment

- 33 tool holders Capto (Sandwik)
- 1 motorized Traub
- 2 hidraulic clamps (Hainbuch)
- 1 self-centering tool (Rohm)
- 1 clamp holder (Hainbuch)
- 1 workpiece chucks (Schunk)
- 1 high pressure pump

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
