- Takisawa NEX-350 Lathe
This Takisawa NEX-350 Lathe was manufactured in the year 2011. It is equipped with a TAKISAWA TURN-i FANUC control unit. The machine has a spindle speed of 2500 rpm.
Overview
- brand: Takisawa
- year: 2011
- MODEL: NEX-350
- application type: Turning
- Location: Italy
- machine type: Lathe
- availability: Sold
- control unit brand: Takisawa
Technical Information - Takisawa NEX-350
General Data
- Measurements width: 5000 mm
- Measurements depth: 2100 mm
- Measurements height: 2340 mm
- Machine weight: 11000 kg
Control Unit
- Brand: Takisawa
- Model: Turn-i FANUC
Main drive
- Number of spindles: 1
- Spindle speed range: 2500 1/MIN
- Tool taper: JIS. A2-11
Movement
- X-AXIS Movement: 390 mm
- Y-AXIS Movement: 1600 mm
Turret
- Number of turrets: 1
Additional Information
- Technical Machine Benefits:
- - Maximum rotation diameter: 820 mm
- - Maximum turnable diameter: 620 mm
- - Maximum turnable length: 1510 mm
- - Maximum bar diameter: 105 mm
- - Spindle bearing inner diameter: 160 mm
- - Further information on work area and tool interferences par. 2. 4. 2
- - Bar passage diameter: 117 mm
- - Self-centering / collet technical characteristics: see value preface of this instruction manual
- - Tool turret : turret type: 12t, rotation speed: 24000 rpm
- - Tool stem height: 32
- Qualitative Machine Benefits:
- - Number of tools on the turret: 12
- - Boring rod diameter: 50
- - Feed rate x axis feed speed: 16 m/mm y axis feed speed: 16 m/mm z axis feed speed: 20 m/mm
- - Tailstock tailstock stroke: 1600 mm tailstock chuck diameter: 150 mm tailstock chuck taper: mt#5 tailstock spindle stroke: 120 mm
- - Numerical control (cn) type of control and characteristics: see details in par. 2. 3. 1 electricity supply *1 electrical power supply: 400 vac ±10% 3f+pe frequency: 50+60 hz control circuit voltage: 24 vdc installed power: 59 kva
- - Motors *1 spindle motor: 30/37 kw rotary tool spindle motor: 5. 5/7. 5 kw b-axis servo motor: --- x-axis servo motor: 4. 0 kw y-axis servo motor: -- kw z axis servo motor: 7 kw indexing motor: 1. 2 kw turret hydraulic system motor: 1. 5 kw lubrication system motor: 0. 004 kw cooling system motor: 0. 4 kw
- - Pneumatic supply: 0. 6 ÷ 0. 8 mpa feed temperature: 5 ÷ 40 °c without solid residues working pressure: 0. 5 mpa necessary flow rate: 10 litres/min
- - Tank capacity *1 hydraulic power unit: 40 litres cooling lubricant tank: 230 litres lubrication control unit: 2 litres range change: 4 litres
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
