Front view of Mazak Multiplex 6300-II Y machine
Front view of Mazak Multiplex 6300-II Y machine

Mazak - Multiplex 6300-II YCA-TUR-MAZ-2012-00001

Rs. 15,507,200
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This 3-axis Mazak Multiplex 6300-II Y was manufactured in 2012, offering robust capabilities for horizontal turning. Ideal for precision machining, this used machine maintains a solid performance record. Consider the opportunity to buy this Mazak Multiplex 6300-II Y horizontal turning machine. Contact us for more information about this machine.

Overview

  • brand: Mazak
  • year: 2012
  • MODEL: Multiplex 6300-II Y
  • application type: Turning
  • Location: Canada
  • machine type: Horizontal Turning Machine
  • availability: Immediately
  • control unit brand: MAZATROL

Technical Information - Mazak Multiplex 6300-II Y

General Data

  • Measurements width: 1000 mm
  • Measurements depth: 1700 mm
  • Measurements height: 870 mm
  • Machine weight: 11974 kg

Control Unit

  • Brand: MAZATROL

Main drive

  • Number of spindles: 2
  • Spindle speed range: 4000 RPM 1/MIN
  • Spindle motor power: 30 HP
  • Spindle bore: 87,884 mm
  • Number of axis: 3

Movement

  • X-AXIS Movement: 309.88 MM
  • X-AXIS Rapid traverse: 945 IPM
  • Y-AXIS Movement: 76.2 mm
  • Z-AXIS Movement: 605.028 mm
  • Z-AXIS Rapid traverse: 945 IPM

Turret

  • Number of turrets: 2
  • Rotating tools: Yes

Tools

  • Number of stations: 12

    General Data

    • Measurements width: 1000 mm
    • Measurements depth: 1700 mm
    • Measurements height: 870 mm
    • Machine weight: 11974 kg

    Control Unit

    • Brand: MAZATROL

    Main drive

    • Number of spindles: 2
    • Spindle speed range: 4000 RPM 1/MIN
    • Spindle motor power: 30 HP
    • Spindle bore: 87,884 mm
    • Number of axis: 3

    Movement

    • X-AXIS Movement: 309.88 MM
    • X-AXIS Rapid traverse: 945 IPM
    • Y-AXIS Movement: 76.2 mm
    • Z-AXIS Movement: 605.028 mm
    • Z-AXIS Rapid traverse: 945 IPM

    Turret

    • Number of turrets: 2
    • Rotating tools: Yes

    Tools

    • Number of stations: 12

      Additional equipment

      • - Max Cutting Length (Chucker): 225 mm
      • - Max Distance Between Spindle Faces: 1450 mm
      • - Min Distance Between Spindle Faces: 249.42mm

      Additional Information

        Machine Benefits

        • Technical Machine Benefits:
          • - Max turning diameter: 430. 02mm
          • - Max turning length: 650. 24 mm
          • - Max swing: 430. 022 mm
          • - Standard cutting diameter: 330. 2 mm
          • - Chuck size: 254 mm
          • - Rotary tool available positions: 12 per turret
          • - Spindle nose: a2-8
          • - Bar capacity: 76mm
          • - Spindle indexing (c axis): 0. 001 degrees
          • - Mill spindle speed: 4000 rpm

        Extra information

        • - Machine still under power

      *There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
