- HWACHEON HI-ECO 450A YMC Lathe
This Hwacheon HI-ECO 450A YMC lathe was manufactured in 2013. It features a Fanuc 0i-TD control, a spindle speed of 3,500 rpm, and a spindle power of 22/18.5 Kw. The machine offers a maximum rotating diameter of Ø 700 mm and a workable length of 637 mm. It includes a tool turret with 12 live tool positions and a chip evacuator. For more information about this lathe, please reach out to us.
Overview
- brand: HWACHEON
- year: 2013
- MODEL: HI-ECO 450A YMC
- production hours: 23101
- application type: Turning
- Location: Italy
- machine type: Horizontal Turning Machine
- availability: Sold
- control unit brand: Fanuc
Technical Information - HWACHEON HI-ECO 450A YMC
Control Unit
- Brand: Fanuc
- Model: 0i-TD
Main drive
- Spindle speed range: 3500 1/MIN
- Spindle motor power: 22 / 18.5 Kw
Movement
- X-AXIS Movement: 280 mm
- Y-AXIS Movement: ± 60 mm
- Z-AXIS Movement: 790 mm
Additional Information
- Technical Machine Benefits:
- - Max. Rotating diameter Ø 700 mm
- - Max. Rotating diameter on pallet Ø 550 mm
- - Turning diameter Ø 254-420 mm
- - Max length workable 637 mm
- - Self-centering diameter Ø 250 mm
- - Spindle connection asa 2-8
- - Spindle hole Ø 90 mm
- - Bar passage Ø 76 mm
- - Indexing 0. 001 °
- - Tool turret with 12 live tool positions
- Qualitative Machine Benefits:
- - Several holders included
- - Accessories chip evacuator
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
