Engel - VICTORY 500/80DE-INJ-ENG-2011-00007

Name: Engel VICTORY 500/80
Brand: Engel
SKU: DE-INJ-ENG-2011-00007
Price: 1852000 INR
Availability: InStock

Rs. 1,852,000

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Plastics Processing Machinery
➤ Used Engel VICTORY 500/80 For Sale | gindumac.com

Show in original language

This hydraulic injection moulding machine was manufactured in 2011. It features an 800 kN clamping force and a screw diameter of 45mm, capable of a shot volume of 306ccm. The platen size is 670mmx670mm, and it can handle a mould opening height from 300mm to 900mm. Consider the opportunity to buy this Engel VICTORY 500/80 hydraulic injection moulding machine. Contact us for more information about this machine.

Overview

brand: Engel
year: 2011
MODEL: VICTORY 500/80
application type: Injection Moulding
Location: Germany
machine type: Hydraulic Injection Moulding Machine
availability: Immediately
control unit brand: ENGEL

Technical Information - Engel VICTORY 500/80

General Data

Machine weight: 5300 KG

Control Unit

Brand: ENGEL
Model: eco victory 500/80

Injection Unit

Screw diameter: 45 mm
Stroke volume: 306 ccm CM³
Injection pressure: Specific max 1598 bar
Screw speed: 162.2ccm/s max

Clamping unit

Clamping force: 800 kN
Opening stroke: 458 mm
Mould height min: 300 mm
Mould height max: 900 mm
Size of mold platens: 670 mm x 670 mm
Ejector stroke: 100 mm
Ejector force for / back: 39.8 kN

Additional equipment

- Core pull DS 1 time AS 2 times

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Quick stroke/opening stroke
- - Distance between bars: tie-bars loose machine
- - Pumpenantriebsleitung / pump drive power 15 kw
- - Handling system is included in the scope of delivery

Extra information

- Injection unit 1 Schneckendurchmesser / Screw diameter 35/35/40/45 mm Max. Hubvolumen / Max. swept volume 192/192/251/318 cm3 Screw speed max / Screw speed max 400/400/400/320 r/min Screw speed max current / Screw speed max current 320 r/min Einspritzstrom / Injection rate 151/151/197/250 cm3 / s Einspritzstrom erhöht / Injection rate increased 98/98/128/162 cm3 / s Spez. Spritzdruck / Spec. injection pressure Injection pressure 1703/1703/1297/1030 bar Spez. Spritzdruck erhöht / Spec. injection pressure increased Injection pressure increased 2390/2390/2023/1598 bar Nozzle stroke 300 mm Nozzle cont. pressure / Nozzle cont. Pressure 51,9 kN

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
