DOOSAN - V740TSI-TUR-DOO-2005-00001

Name: DOOSAN V740T
Brand: DOOSAN
SKU: SI-TUR-DOO-2005-00001
Price: 5735750 INR
Availability: InStock

Rs. 5,735,750

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used DOOSAN V740T Vertical Lathe For Sale | gindumac.com

Show in original language

This DOOSAN V740T vertical turning machine was manufactured in 2005. It features a maximum swing diameter of 800 mm, turning diameter of 740 mm, and a turning length of 760 mm. The main spindle supports a rotational speed up to 2000 RPM with a motor power of 30 kW. It includes a 12-position turret and rapid traverse rates of 20 m/min for both X and Z axes. If you are looking to get high quality turning capabilities consider the DOOSAN V740T machine we have for sale. Contact us for further details regarding this machine.

Overview

brand: DOOSAN
year: 2005
MODEL: V740T
application type: Turning
Location: Slovenia
machine type: Vertical Turning Machine
availability: Immediately
control unit brand: FANUC

Technical Information - DOOSAN V740T

General Data

Machine weight: 18000 kg

Control Unit

Brand: FANUC
Model: FANUC 18I TB

Main drive

Spindle speed range: 2000 RPM 1/MIN
Spindle motor power: 30 kW
Tool taper: ASA A2-11
Number of axis: 2

Movement

X-AXIS Movement: 380 mm
X-AXIS Rapid traverse: 20 m/min
Z-AXIS Movement: 760 mm
Z-AXIS Rapid traverse: 20 m/min

Turret

Number of turrets: 1

Additional equipment

- Holders for External Turning: HO10-25RL (4 pcs)
- Holders for Face Turning: HF10-25RL (2 pcs)
- Holders for Internal Turning: HB10-50N (4 pcs), HB10-40N (2 pcs)
- Reduction Sleeves: BS 40-10, -12, -16, -20, -25 (2 sets)

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Drive: gear transmission, two stages
- - Maximum swing diameter: 800 mm
- - Maximum turning diameter: 740 mm
- - Maximum turning length: 760 mm
- - Number of positions: 12 x 2
- - External turning: 25 x 25 mm
- - Boring tools: Ø40/60 mm
- - Tool change time: 0. 43 s

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
