Walter Helitronic Power Grinding Machine

Show in original language

This Walter Helitronic Power Grinding Machine was built in 2007 in Germany. It has been working for 44865 hours. This machine is operated through a FANUC Series 310i – MODEL A5 control unit. It can work with a spindle speed up to 7000 rpm. Always serviced by Walter service.

Overview

brand: WALTER
year: 2007
MODEL: Helitronic Power
production hours: 44865
application type: Grinding
Location: Poland
machine type: Grinding Machine
availability: Sold
control unit brand: FANUC

Technical Information - WALTER Helitronic Power

General Data

Measurements width: 2427 mm
Measurements depth: 2930 mm
Measurements height: 2273 mm
Machine weight: 4200 KG

Control Unit

Model: Series 310i – MODEL A5
Brand: FANUC

Main drive

Spindle speed range: 7000 1/MIN
Spindle motor power: 24 kW

Movement

X-AXIS Movement: 460 mm
Y-AXIS Movement: 320 mm
Z-AXIS Movement: 660 mm

Media

Main electronic connection: 400V / 50Hz
Power consumption: 25 kVA

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Max. Grinding wheel diameter: 200 mm
- - Spindle dia. : 80 mm
- - Fire suppression system
- - Oil mist filter
- - Set of tool holders
- - Software licenses: walter window mode / helitronic tool studio
- - Possibilities of grinding: cutters / drills / taps / reamers / special tools
Qualitative Machine Benefits:
- - Always serviced by walter service

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
