TORWEGGE - TG2 Parquet production lineDE-OTH-TOR-2001-00001

Name: TORWEGGE TG2 Parquet production line
Brand: TORWEGGE
SKU: DE-OTH-TOR-2001-00001
Price: 42343600 INR
Availability: InStock

Rs. 42,343,600

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Wood Working
➤ Used TORWEGGE TG2 Parquet production line | For Sale

Show in original language

This Other (Wood) was manufactured in 2001. The TORWEGGE TG2 Parquet production line includes multiple components for efficient wood processing, handling lengths from 600 to 1500 mm and widths from 125 to 250 mm. It features robust motor powers and comprehensive extraction capabilities, ensuring high operational standards. If you are looking to get high quality wood processing capabilities consider the TORWEGGE TG2 machine we have for sale. Contact us for more information about this machine.

Overview

brand: TORWEGGE
year: 2001
MODEL: TG2 Parquet production line
application type: Other Woodworking Machinery
Location: Germany
machine type: Other (Wood)
availability: Immediately

Technical Information - TORWEGGE TG2 Parquet production line

Additional Information

Extra information

- Motor Positions and Powers: Length Milling Machine: 6 motor positions left and right + 1 extra spindle on each side Motor Power for Milling Tools: 11 kW, 7.5 kW, 7.5 kW, 7.5 kW, 7.5 kW, 7.5 kW Motor Power for Chain: 15 kW Cross Milling Machine: 7 motor positions left and right + 1 extra spindle on each side Motor Power for Milling Tools: 3.7 kW, 3.7 kW, 7.5 kW, 7.5 kW, 7.5 kW, 7.5 kW, 7.5 kW Motor Power for Chain: 11 kW Workpiece Size of Finished Products: Length: Min 600 mm, Max 1500 mm Width: Min 125 mm, Max 250 mm Thickness Max: 20 mm Media Compressed Air Connection: Infeed Machine: 3/4" diameter Milling Machines: 1" supply splitting up in 3/4" length and 3/4" cross Intermediate and Outfeed Part: 3/4" each Extraction Specs: Ventilator: F7.V1 Power: 132 kW RPM: 1500 rpm Axis Diameter: 80 mm Tube Diameter: 800 mm Speed: 25 m/s Flow Rate: 45239 m³/h Electrical Consumption: Power on Idle: Approximately 25 kW Power during Full Production: 40 - 60 kW and 70 - 95 A

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
