SORALUCE SORA 4 milling machine

Show in original language

This SORALUCE SORA 4 milling machine was built in the year 1989 in Spain. It is equipped with a SIEMENS SINUMERIK 810 control unit. The machine has a spindle speed of 15-1600 rpm.

Overview

brand: Soraluce
year: 1989
MODEL: SORA 4
application type: Milling
Location: Spain
machine type: CNC Milling Machine
availability: Sold
control unit brand: SIEMENS

Technical Information - Soraluce SORA 4

General Data

Measurements width: 9800 mm
Measurements depth: 4050 mm
Measurements height: 3600 mm
Machine weight: 24000 kg

Control Unit

Model: SINUMERIK 810
Brand: SIEMENS

Main drive

Spindle speed range: 15 - 1600 rpm 1/MIN
Spindle motor power: 18 kw

Movement

X-AXIS Movement: 4000 mm
Y-AXIS Movement: 1000 mm
Z-AXIS Movement: 1600 mm

Table

Outer length: 4000 mm
Outer width: 1000 mm
Table load: 10000 kg

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Spindle model: automatic axes a/b - a 2,5º-b 2,5º.
- - Cone: iso 50
- - Tool magazine: 60 units
- - Chip extractor: yes

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
