➤ Used POSmill CE 1000 For Sale | gindumac.com

Show in original language

This 3-axis POSmill CE 1000 vertical machining center was manufactured in 2018. It features a robust construction weighing 8 tonnes, a Heidenhain iTNC 530 control system, and a spindle motor capable of 10,000 rpm with an SK 40 holder. The machine includes a 40-slot tool changer with double gripper and a high-pressure coolant system at 20 bar. Ideal for those looking to buy this POSmill CE 1000 vertical machining center. Contact us for further details regarding this vertical machining center.

Overview

brand: POSmill
year: 2018
MODEL: CE 1000
application type: Milling
Location: Germany
machine type: Vertical Machining Centre
availability: Sold
control unit brand: HEIDENHAIN

Technical Information - POSmill CE 1000

General Data

Machine weight: 8000 KG

Control Unit

Model: iTNC 530
Brand: HEIDENHAIN

Main drive

Spindle speed range: 10,000 1/MIN
Spindle motor power: SK 40
Number of axis: 3

Movement

X-AXIS Movement: 1000 mm
Y-AXIS Movement: 600 mm
Z-AXIS Movement: 600 mm

Table

Outer length: 1200 mm
Outer width: 600 mm

Media

Oil water separator: Yes
Chip conveyor: Yes

Additional equipment

- 3D probe
- Tool holders
- Tool changer 40-fold with double gripper
- Extra pump for chip flushing
- Extra pump for coolant at the spindle
- Large IKZ system with 20 bar
- Air through the spindle via M function
- Air at the spindle via M function
- Coolant nozzles around the spindle via M function
- Side windows for long parts

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Solid machine construction with 8 tonnes
- - Heidenhain glass scales in all axes
- - Heidenhain axis motors
- - Heidenhain protective air for the glass scales
- - Heidenhain spindle motor
- - Heidenhain diagnostic unit
- - Heidenhain large electronic handwheel
- - Heidenhain preparation for 4th + 5th axis
- - Tool loading - main time parallel
Qualitative Machine Benefits:
- - Fully protected cabin
- - Active enclosure cooler incl. Core cooling
- - Centralised oil lubrication
- - The machine is fully functional and a new spindle was installed in 2022

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
