Joemars AWT655S Erosion machine

Show in original language

This Joemars AWT655S Erosion machine was manufactured in the year 2007 in Taiwan. It is equipped with a HGC control unit. The machine has a wire diameter of 0,2 mm.

Overview

brand: Joemars
year: 2007
MODEL: AWT 655S
application type: EDM
Location: Germany
machine type: Wire EDM Machine
availability: Sold

Technical Information - Joemars AWT 655S

General Data

Measurements width: 2600 mm
Measurements depth: 2130 mm
Measurements height: 2060 mm
Machine weight: 2100 kg

Movement

X-AXIS Movement: 350 mm
Y-AXIS Movement: 250 mm
Z-AXIS Movement: 210 mm
U/V Movement: +/- 40 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Wire diameter: 0. 2 mm
- - Workpiece height: 33 mm
- - Number of cuts: 3

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
