DECKEL MAHO (DMG) Type DMU 60 T Universal machining center

Show in original language

This DECKEL MAHO (DMG) Type DMU 60 T Universal machining center was manufactured in the year 2001 in Germany. It has 13100 spindle hours and works with a coolant system HP 20 BRS IKZ. It has 4 axis and operates with a spindle speed up to 18000 rpm. Includes a table dimensions of 1000 x 600 mm.

Overview

brand: DECKEL MAHO
year: 2001
MODEL: (DMG) Type DMU 60 T
production hours: 13100
application type: Milling
Location: Germany
machine type: Universal Machining Centre
availability: Sold

Technical Information - DECKEL MAHO (DMG) Type DMU 60 T

Control Unit

Model: TNC 430

Main drive

Number of spindles: 1
Spindle speed range: 18000 1/MIN
Tool taper: SK 40
Main motor power: 15 kW

Movement

X-AXIS Movement: 630 mm
Y-AXIS Movement: 560 mm
Z-AXIS Movement: 560 mm

Table

Outer length: 1000 mmm
Outer width: 600 mm
Table load: 400 kg

Media

Main electronic connection: 400 V
Power consumption: 26 kVa

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Coolant system hp 20 brs ikz
- - Screw conveyor
- - Several tool holders
- - Feed range 20 - 10,000 mm / min
- - Rapid traverse x and y axes 26 m / min
- - Rapid traverse z-axis 20 m / min
- - Tool change unit 20 item no.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
