AXA - VHC-2DE-MIL-AXA-2010-00001
Do you have further questions? Contact us.
![sales contact](https://storage.googleapis.com/gindumac-public/team/sergi_guardia.jpg)
Sergi Guardia
+49 162 4027635
s.guardia@gindumac.com
![whatsapp](https://gindumac.s3.eu-central-1.amazonaws.com/images/email-icons/whatsapp.png)
- GINDUMAC
- Products
- Machine Tools
- ➤ Used DOOSAN Puma ST32G - Lathe For sale | gindumac.com
This 7-axis DOOSAN Puma ST32G was manufactured in 2013, offering advanced turning capabilities. Equipped with a Fanuc Series 31i-Model B control unit, it supports simultaneous axis operation and features a spindle speed range up to 8000 1/min. Additional equipment includes LNS Express 332 S2 Bar Feed, LNS Swarf Conveyor, and more. Ideal for the oil & gas industry, this lathe represents a significant opportunity to buy this DOOSAN Puma ST32G Lathe. Contact us for further details regarding this Lathe.
Overview
- brand: AXA
- year: 2010
- MODEL: VHC-2
- production hours: 35000
- application type: Milling
- Location: Germany
- machine type: Machining centers (vertical)
- availability: Sold
- control unit brand: Siemens
Technical Information - AXA VHC-2
Control Unit
- Brand: Siemens
- Model: 840 D pl
Main drive
- Spindle speed range: 30-9000 1/MIN
- Spindle motor power: 56 kW
- Tool taper: SK50
- Number of axis: 5
Movement
- X-AXIS Movement: 3000 mm
- X-AXIS Rapid traverse: 40 m/min
- Y-AXIS Movement: 650 mm
- Y-AXIS Rapid traverse: 40 m/min
- Z-AXIS Movement: 800 mm
- Z-AXIS Rapid traverse: 30 m/min
Table
- Outer length: 3750 mm
- Outer width: 600 mm
Additional Information
- Technical Machine Benefits:
- - Bearings and seals new // disk springs new
- - Lubrication lines new // motor winding new
- - Simulat processing possible
- - Table is 3. 750 m and x-travel is 3 m. The rotary table has d. 600 mm.
- - Cooling housing new
- - Tool holders sk50
- - Rotary table rta 4d-600
- - A-axis - 221 pcs
- - Forkardt chuck 200mm with chuck flange and centering bolt
- - Cnc rotary table: 600 mm
- Qualitative Machine Benefits:
- - Spindle, housing etc. Completely overhauled for eur 30000
- - Machine still under power
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
Documents
Sergi Guardia
Payment Terms
Payment in advance
Asset Financing
